Ninebot Mecha Kit

It is a product modified based on the balance vehicle series: it has more gameplay (the organic combination of speed and combat; driving speed and drift experience; combat operation mode; water bomb shooting)

The applicable age of the Ninebot Mecha Kit is 14+, the applicable height is 110-180cm, and the maximum load is 100kg. It is forbidden for two or more people to ride in the kit. When used by minors, adult supervision is required. When driving the Mecha, you must wear helmet protection, and you must wear goggles when using the shooting function.

Various play methods

The organic combination of speed and combat, driving and shooting toys from the first perspective;

Play more with one vehicle: mech chariot, remote control chariot, balance vehicle;

Intelligent sound effects and Bluetooth speaker function;

Temperament leader

Mecha fortress style design, black and white, and innate combat leader temperament;

The operation mode of mech fighters can enter the fighting state at any time;

Cool lighting effects;

Special Design

The ultimate man-machine and size design, indoor and outdoor high for adults and children;

Replaceable, repairable, expandable, quick-release and quick-installation design, push and pull, a "combat" trip that just walks away;

Each part is crafted, just to make you use it more comfortably: the seat, rocker, and pedal fully consider comfort and practicality;

I tell you everything I know: all-round tips, easy to use, easy to use;

Security Guarantee

The heart of a urchin, the body of a tough guy;

Combat safety latch: rocker induction type safety protection, App speed and shooting control;

Weapons in hand, battle Mecha on the body: practical accessories;

Scalability

Unprecedented compatibility, as long as you have a balance vehicle, come to fight;

Support large-capacity battery expansion, the battle will last longer;

The high-end version will be launched in March 2021.

Perfectly matched with the Ninebot balance vehicle, the balance vehicle becomes a new toy. It is both a mecha tank and a balance vehicle. It is part of the balance vehicle ecology, focusing on the ecological concept of the balance vehicle. You have a balance vehicle that can be transformed into a kart or drift vehicle. It is fun and not expensive, one product has two ways to play.

The Ninebot Mecha Kit has particularly good flexibility. It can be practiced at home, enter the elevator and turn 360 degrees, and can drive from home to the elevator and then downstairs to the place where you want to play, such as residential quarters and parks. It is no longer limited to space. usage of.

Warning: It is forbidden to drive the Ninebot Mecha Kit on the road, near motor vehicles, slopes and their nearby areas, steps and their nearby areas, swimming pools and other areas with water, etc., which may affect normal driving or may affect driving safety.

One vehicle for more play, it’s the Ninebot Mecha Kit, it’s a remote control tank, and it’s also a balance vehicle.

The balance vehicle chassis has strong power, the maximum speed is 14km/h*;

Differential chassis + universal wheel design, everyone is a drift expert;

Equipped with dual water bomb shooting module, first-person shooting combat pleasure;

For details, please refer to the Ninebot official website https://store.segway.com/

Intelligent voice reminder and teaching;

Cool speed drift sound waves and battle shooting sound effects.

High-brightness shooting light and shadow lamp, illuminating light and shadow and spray effect;

Chassis atmosphere light, full of light;

The balance vehicle chassis comes with brakes, wheel lights, and atmosphere lights;

For details, please refer to Ninebot official website https://store.segway.com/

Easy to store, the whole kit can be easily put into the SUV or the seat can be put down in the hatchback;

 The weight of the kit is less than 12kg (without balance vehicle chassis);For details, please refer to Ninebot official website https://store.segway.com/

Buckle & screw quick release design, enter combat state in 5 minutes;

For details, please refer to Ninebot official website https://store.segway.com/

APP operation instruction video with link-to be updated

The rear wheel of the mecha kit is composed of two 5-inch universal wheels.

The waterproof rating of the Mecha kit is IPX4. It is forbidden to drive outdoors on rainy days. For your personal safety, outdoor riding is not recommended under other severe weather.

The exterior plastic parts of Ninebot Mecha Kit are mainly PC materials, but also PC+ABS, PP, PA6+GF and other materials; the frame is made of steel.

The serial number of the Ninebot Mecha Kit can be seen on the left side of the box, certificate, and back shell, format: NxxxxCxxxx

Each Ninebot Mecha Kit will test various functions before leaving the factory, and only allow it to leave the factory if it is normal to ensure that each product meets the Ninebot quality standards. Therefore, the slight dirt/wear of the tires is caused by the marks produced by the road test. It is not a quality problem, and it is not a retread product. Please rest assured to use.

First, with the logo side of the armrest facing outwards, slide the buckle cover on the side of the handrail outward, and then insert the wire on the frame through the hole at the bottom of the armrest. After docking the terminal, insert the wire into the armrest and close the buckle cover. Slide the armrest forward until you hear a click and lock the armrest.

When disassembling: pinch the buckles on both sides below, and pull the armrest backward. Open the buckle cover, find the wiring harness and separate the terminals.

Lift the bumper and place the frame on the balance vehicle. Please place the balance vehicle in the direction shown in the figure (the power button is facing forward). Pass the safety strap through the bottom of the balance vehicle, and then pass through the strap fixing hole to tighten the strap.

The upgrade package has not been released yet, and it will be available in late January 2021.

During driving, the unilateral universal wheel is off the ground, which may be caused by the influence of the road surface, or the driver's weight is too light and the load is not enough.

When braking, the center of gravity will move forward to a certain extent, causing the rear universal wheel to leave the ground.

The vehicle is in (safe mode) with a speed limit of 5km/h.

Ninebot balance vehicle-Mecha kit has three driving modes, which can be switched in the APP

Safety mode (speed limit 6km/h),

Novice mode (speed limit 10km/h),

Sports mode (speed upper limit 14km/h).

After completing all the novice teaching, you can use the App to design the novice mode to unlock the speed limit of 10km/h, and the cumulative mileage can exceed 300 meters, and you can set the sport mode to unlock the speed limit of 14km/h through the App.

a)      Connect the balance vehicle APP, change the mode to Ninebot Mecha Kit mode, and disconnect the Bluetooth.

b)      The balance vehicle and the Mecha kit is on.

c)      Start pairing: Press and hold the Mecha kit switch until you hear the sound effect.

d)      Complete the pairing: long press the balance vehicle switch until you hear the sound effect.

* When pairing, please make sure that there is only one pairable balance vehicle in the Bluetooth range to turn on; and the balance vehicle Bluetooth is not connected to other devices or apps.

Find the lighting effect setting in the APP and switch the corresponding mode.

You can remotely control the Ninebot Mecha Kit and shoot remotely through the APP.

Method: Ninebot Mecha Kit main page>Bluetooth remote>Drag the virtual handle to control the direction+click or long press the right virtual shooting button to shoot.

You can remotely control the Ninebot Mecha Kit and shoot remotely through the APP.

Method: Ninebot Mecha Kit main page>Bluetooth remote>Drag the virtual handle to control the direction+click or long press the right virtual shooting button to shoot.

You can remotely control the Ninebot Mecha Kit and shoot remotely through the APP.

Method: Ninebot Mecha Kit main page>Bluetooth remote>Drag the virtual handle to control the direction+click or long press the right virtual shooting button to shoot.

You can remotely control the Ninebot Mecha Kit and shoot remotely through the APP.

Method: Ninebot Mecha Kit main page>Bluetooth remote>Drag the virtual handle to control the direction+click or long press the right virtual shooting button to shoot.

You can remotely control the Ninebot Mecha Kit and shoot remotely through the APP.

Method: Ninebot Mecha Kit main page>Bluetooth remote>Drag the virtual handle to control the direction+click or long press the right virtual shooting button to shoot.

When using the Ninebot Mecha Kit for the first time, the Ninebot Travel APP will have a tutorial for beginners. Please follow the prompts to activate.

When using the Ninebot Mecha Kit for the first time, the Ninebot Travel APP will have a tutorial for beginners. Please follow the prompts to activate.

Please follow the app prompts to upgrade the firmware of the Ninebot Mecha Kit;

Upgrading the firmware will improve the use of the vehicle and fix related bugs.

You can connect the Ninebot Mecha Kit Bluetooth with your mobile phone, cool music can make driving more fun!

Method: Open the mobile phone's Bluetooth> search for the device name as MechaAUDxxxx> pair and connect, after the pairing is successful, you can play Bluetooth audio through other audio software.

About 10m

There are three shooting modes: continuous shooting mode, burst shooting mode and simulated shooting, which can be selected in the shooting component settings in the app.

After turning on "Whether shutting down the vehicle is allowed to lock" in the APP vehicle settings, the chassis will automatically shut down after 5 minutes of static state. When the kit is disconnected from the chassis for 5 minutes, it will also automatically shut down.

There are two ways of deceleration:

Slow braking-release your hands

Fast braking-pull both hands back to stop.

Start: Press the Mecha kit power switch first, then press the balance vehicle switch;

Trigger joystick protection: Hold the rocker with both hands, (you can operate it after triggering the rocker protection, and there will be a beeping prompt after the trigger. If you can’t respond by holding the rocker, please release your hands and try again)

Forward; both joysticks move forward at the same time;

Braking: slow braking-both left and right joysticks return to the neutral position, fast braking-pull both hands back to stop;

Reversing: Both joysticks move backward at the same time;

Steering: Push the rocker on one side forward, or push one side forward while the other side pull back.

If the balance vehicle is not switched to “Ninebot Mecha Kit Mode”, it will cause the center of gravity to move forward/rearward after booting, and the Ninebot Mecha Kit cannot be upgraded, and the throttle brake will not work. Please perform the following operations on the balance vehicle before assembling the Ninebot Mecha Kit:

1) Download and install the Ninebot app.

2) Open the APP, search for and connect to your balance vehicle.

3) Click "Mode Switch" in the upper left corner of the APP page → click "Ninebot Mecha Kit Mode" on the settings page and turn it on.

Note: People who have not upgraded the balance vehicle separately are forbidden to sit in, so as to prevent excessive deviation of the balance point of the balance vehicle from causing injury due to sudden acceleration.

The balance vehicle is in the "Ninebot Mecha Kit mode", so it cannot ride normally. You must be connected to the app, and you will be prompted to exit the "Ninebot Mecha Kit mode". Click OK to exit. If not prompted, enter the setting interface and close it manually.

The actual speed cannot reach the speed value displayed by the app?

There are several reasons for this situation:

a)      Please check whether the front and rear wheels are jammed by foreign matter, and check whether the mudguards fall off and jam the front wheels, which may cause a big difference in speed due to interference;

b)      Uphill section;

c)      The balance vehicle battery is too low to limit the speed.

Considering the convenience of use, a safety strap is used to secure the balance vehicle chassis and the kit. A slight shaking is normal. If there is a large amount of shaking, please check whether the strap is tightly tied to the balance vehicle and the Mecha kit.

When the vehicle is turned on, you need to hold the rocker with both hands at the same time, and you hear a "di" sound, the spotlight lights up, and you can perform driving operations.

When both hands are released from the joystick, the vehicle will enter the dormant state, and the driver needs to repeat the above actions.

If the above cannot be solved, please contact after-sales service.

Hello, there are the following situations when the joystick fails:

1) There is no beep when holding the joystick with both hands at the same time, and trying again is invalid;

2) Pull the joystick forward or backward without resilience;

3) Only one side of the left and right joysticks can perform driving actions;

The above faults are all damages to the internal wiring harness or rocker components, and you need to contact after-sales service for repair.

Hello, with the normal use of the gearbox, there will be a certain degree of power attenuation, which is a normal phenomenon and is not a product performance or quality problem

About 450 rounds per side.

It is not recommended to continue to empty the gun, and you can switch to simulated shooting without crystal bullets.

Initial velocity 17m/s, rate of fire around 10/s

Hello, first hold the joystick with both hands, hear the beep sound, and then press the shooting button, the water bomb will be launched, and the mode can be switched in the APP. When the kit battery is lower than 30%, it will stop powering the shooting function.

The range of the crystal bomb is generally 3~4m, and it may fluctuate depending on the type of water bomb, the degree of bubble generation and the environment.

The principle of the Ninebot Mecha Kit shooting component is gas compression ejection. It is normal for the shooting strength of different shooting components to have certain differences. In addition, the shooting intensity may fluctuate depending on the type of water bomb, the degree of water bombs and the environment.

The principle of the Ninebot Mecha Kit shooting component is gas compression ejection. It is normal for the shooting strength of different shooting components to have certain differences. In addition, the firing intensity may fluctuate depending on the type of water bomb, the degree of bubble generation, and the environment. In addition, due to the difference in the level of ground level of different vehicles, the angle of emission is different, resulting in a difference in range.

The shooting function of the Ninebot Mecha Kit modification kit meets the requirements of regulations. The main shooting function is the shape of the vehicle. The specific kinetic energy of the crystal bomb meets the requirements of relevant regulations.

(The appearance of the shooting component does not have the shape of a standard gun, and the specific kinetic energy of the Ninebot Mecha Kit muzzle is lower than 0.16J/c㎡, which is not within the range of 0.16~1.8J/c㎡ for the simulated gun specific kinetic energy specified by the country)

In the event of an accident, the launch tube is blocked by fragments of water bombs or water bombs that exceed the standard size, making the water bombs unable to launch.

Please remove the remaining water bombs in the magazine and leave the Mecha kit for more than 1 day. After the water bombs evaporate, the size will be reduced and the fault can be eliminated.

* Do not use hard tools to forcibly unblock the launch tube to avoid damage to the Mecha kit.

There is no problem to fix the shooting component with two screws, and it does not affect the normal use of the shooting component. The free fixed position is an extra spare hole reserved in the design process of the Ninebot Mecha Kit shooting component, and it does not need to be assembled under normal conditions.

Check whether the armrest terminals are properly inserted and whether the terminal pins are bent.

If it still alarms, the gearbox may be damaged or the joystick may malfunction

High-end version accessories include: instruction manual, NANO adapter bag, 4M allen key + screw X4, rechargeable battery assembly + charging cable, foot control removal kit, foam sticker X4, (gift: headlight, goggles, water Bomb 6. bag, water bomb bottle X4 + external pendant, shooting target X6, protective pad X2)

Standard version accessories include: instruction manual, NANO adapter bag, 4M Allen key + screw X4, rechargeable battery assembly + charging cable, foot control removal kit, foam sticker X4, (gift: goggles, water bomb 2 packs , Water bomb bottle, shooting target X6, protective pad X2)

Use pure water, soak for about 4 hours at room temperature. It is recommended to keep it out of water for no more than 24 hours.

The crystal bomb is made of a non-toxic and harmless composite material, which absorbs water and expands. Please use it as required.

The Ninebotbalance vehicle-Mecha kit uses a lithium battery. The standard version takes about 3 hours to charge. The battery capacity will not be less than 70% of the rated capacity after 300 cycles of charging and discharging. It is recommended to charge when the battery is about 10% remaining to avoid excessive discharge. , Which can extend battery life.

The battery is used to power the kit's Bluetooth board, Bluetooth speakers, shooting components, ambient lights, indicator lights, etc.

You can check the remaining power of the kit battery in the APP interface, or you can judge the remaining power of the kit battery through the power indicator.

The batteries of the Ninebot Mecha Kit kit can be used for all types of balance vehicle chassis to ride a complete endurance. If the shooting function and Bluetooth speaker function with higher power consumption are used, the endurance time will be reduced to a certain extent.

The standard version will charge for about 3 hours.

Take out the battery pack from the battery compartment and connect the charger for charging. When charging, the USB end of the charging cable lights up with a red light; when it is fully charged, the red light goes out. Note that you need to bring your own 5V 1~2A charging head to avoid using a large current charging head to damage the charging cable

Standard version 2000mAh.

Need to follow the steps below to troubleshoot:

a)      Check whether the contact is bad: re-plug the connections on both sides of the charger to see if it can be resolved.

b)      Check whether the charging cable is faulty: the charging cable is connected to the power supply, and the battery is not connected. Observe whether the indicator light of the charger is flashing (red). If it does not light, it means the charger is faulty, and you need to contact the after-sales service for repair.

c)      Check the charging status whether the indicator light of the charger is red. If the indicator light is not on, it may be that the charger is faulty, or the battery is damaged. You need to contact after-sales service for repair.

d)      The battery may overheat after riding, and it cannot be charged at this time. After cooling down for a while, plug in the charger to charge.

It is recommended that after each use, make sure that there is no crystal bomb in the magazine and wipe the residual moisture on the surface.

The serial number of the Ninebot Mecha Kit can be seen on the left side of the box, certificate, and back shell, format: NxxxxCxxxx

Customers who need to return or exchange products need to contact the seller directly for communication and application. If you have any questions, you can call the official service phone for consultation.

Welcome to the official website of Ninebot: http://www.ninebot.com

Service Hotline: 400-607-0001 ext. 9

If the vehicle sold as kit model, when the whole vehicle is returned, it must be returned at the same time.

The Ninebot Mecha Kit adapted products are shown in the figure below: please refer to the manual for details.

1.  Take out about 900 rounds of water bombs (about a bottle cap) and pour them into a water basin and other containers.
2. Inject 2500ml of pure water at room temperature.
3. Soak for more than 4 hours.
4. The water bomb bottle can be used to store and vehiclery the brewed water bomb.

* Tap water and mineral water may not soak to the specified size due to different water hardness. If there are abnormal situations such as the water bomb can not be soaked, please use pure water at room temperature or extend the soaking time appropriately. After the water bomb is fully soaked, the size is between 7~8mm. The first time it is soaked, the number of water bombs may not be known. It is recommended to use an open container, such as a water basin, for soaking.

Tip: The single-sided magazine has a capacity of about 450 water bombs.

For details, please refer to Ninebot official website https://store.segway.com/

After a period of use, the foot mat will wear out, so you can replace it yourself.

Step

1. Use an Allen wrench to loosen the screw of the foot mat.
2. Align the new protective pad with the hole and tighten the screw.

For details, please refer to Ninebot official website https://store.segway.com/

The high-profile version of the mecha kit is equipped with two left and right water bomb bottle mounting plates for installation on the steel pipes under the left and right handrails.

Step

1. Align the two buckles of the mounting board with the two steel pipes and buckle in.
2. Insert two water bomb bottles into the strap side of the mounting board.

For details, please refer to Ninebot official website https://store.segway.com/

 The headlight is a giveaway of high- end version. The installation steps are as follows.

1. Cut the hanging lamp into the strap slot.
2. Fasten the strap around the bumper.

* It can be charged by connecting a power adapter with a USB charging cable.

For details, please refer to Ninebot official website https://store.segway.com/

The factory default adapter pad (Ninebot balance vehicle adapter pad) is not suitable for Ninebot balance vehicle Nano.

If your vehicle is a Ninebot balance vehicle Nano, you need to replace the Nano adapter pad.

Steps

1.  Use an Allen key to loosen the 4 screws under the adapter pad.
2. Replace the Nano adapter pad, align the holes, and tighten the screws. (Direction: strap hole facing forward)

* If your vehicle is Ninebot balance vehicle Plus, please purchase the "Plus Upgrade Package" before replacing the adapter pad.

For details, please refer to Ninebot official website https://store.segway.com/
